rms Posted May 29, 2019 Report Share Posted May 29, 2019 (edited) On 5/28/2019 at 2:44 PM, malcolm watt said: lovely bike mate I've just finished building my gripper 350 but having timing issues . there docent seem to be any timing marks could anyone shed any light on the matter It should be set 1,3mm to 1,8mm maximum BTDC. This is 14,5° to 17° BTDC. On my gripper, i have to turn the stator full clockwise (checked with timing lamp). Do you have to original cylinder head gasket ? Edited May 29, 2019 by rms Quote Link to comment Share on other sites More sharing options...
woody Posted May 29, 2019 Report Share Posted May 29, 2019 You say it should be between 1.3 and 1,8mm BTDC with the stator fully clockwise. That's fully retarded. If that is how you like it then that is ok but fully retarded isn't the Ossa recommendation for trials model which is usually 2.5 - 3mm before TDC Ultimately it's the owner's personal choice how they set it Quote Link to comment Share on other sites More sharing options...
rms Posted May 29, 2019 Report Share Posted May 29, 2019 The top engine of the TR80 is different from the MAR and TR77 (gaskets for the bottom engine can be used, but not for the top engine), they have a thin head gasket (copper, something like 0,6mm thickness). TR80 is not set up like other Ossa trials, and 1,3 - 1,8mm is the way it should be. Full clockwise is full retarded, this is what I meant ? Quote Link to comment Share on other sites More sharing options...
