exman Posted 15 hours ago Report Share Posted 15 hours ago Since I wasn't careful enough during dismantling, I am not sure whether Cushion arm plates are in right position or I have turned it upside down. It can't be determined from the photos in the Owners Manual.. Quote Link to comment Share on other sites More sharing options...
lemur Posted 15 hours ago Report Share Posted 15 hours ago You got it right; the lobe with the larger contact surface goes to the swingarm, smaller one bolts to the dog bone linkage, longest arm bolts to the shock. 1 Quote Link to comment Share on other sites More sharing options...
exman Posted 13 hours ago Author Report Share Posted 13 hours ago Tks mate, I can proceed with assembling now. Quote Link to comment Share on other sites More sharing options...
